Camera interfaces
Guppy PRO Technical Manual V4.0.0
73
Normal conditions
Error conditions
Blink codes are used to signal warnings or error states (When S1 and S2 blink
together, you see blinking orange):
• S1 means green half of LED
• S2 means red half of LED
• Example: LLC not ready  S1 (3 blinks) + S2 (5 blinks): 3 orange blinks
and afterwards 2 red blinks
Event (GREEN) (RED)
Camera startup During startup all LEDs are switched on consecu-
tively to show the startup progress:
(GREEN + RED) long time

then (GREEN + RED) short time

then GREEN permanent on
Power on GREEN
Bus reset not available
Asynchronous traffic +GREEN pulsing
Isochronous traffic +GREEN pulsing
Waiting for external
trigger GREEN RED
External trigger event GREEN +RED pulsing
Table 21: LEDs showing normal conditions
