Specifications
Guppy PRO Technical Manual V4.0.0
42
Guppy PRO F-033B/C
Feature Specification
Image device Type 1/2 (diag. 8 mm) progressive scan SONY IT CCD ICX414AL/AQ with
HAD microlens
Effective chip size 7.48 mm x 6.15 mm
Cell size 9.9 µm x 9.9 µm
Picture size (max.) 656 x 492 pixels (Format_7 Mode_0)
Lens mount Adjustable C-Mount: 17.526 mm (in air); Ø 25.4 mm (32 tpi)

maximum protrusion: 10.1 mm

(see Figure 26: Guppy PRO C-Mount dimensions on page 68)
ADC 14 bit
Color modes Only color: Raw8, Raw12, Raw16, Mono8, YUV411, YUV422, RGB8
Frame rates 1.875 fps; 3.75 fps; 7.5 fps; 15 fps; 30 fps; 60 fps

Up to 85 fps in Format_7
Gain control Manual: 0-24.4 dB (0.0359 dB/step); auto gain (select. AOI)
Shutter speed 31 µs … 67,108,864 µs (~ 67 s); auto shutter (select. AOI)
External trigger shutter Programmable, trigger level control, single trigger,

bulk trigger, programmable trigger delay
Look-up tables User programmable (12 bit  10 bit); default gamma (0.45)
Smart functions AGC (auto gain control), AEC (auto exposure control), autofunction
AOI, LUT, binning (only b/w), sub-sampling (only b/w), color
correction, hue, saturation, 1 storable user set

only color: AWB (auto white balance)
I/Os One configurable input (optocoupled),

three configurable outputs (optocoupled)
Transfer rate 100 Mbit/s, 200 Mbit/s, 400 Mbit/s, 800 Mbit/s
Digital interface IEEE 1394b (IIDC V1.31), 1 x copper connector
Power requirements DC 8 V - 36 V via IEEE 1394 cable or 12-pin HIROSE
Power consumption Typical
 3.5
watt (@ 12 V DC)
(full resolution and maximal frame rates)
Dimensions 44.8 mm x 29 mm x 29 mm (L x W x H); incl. connectors, without tripod
and lens
Table 14: Specification Guppy PRO F-033B/C
Note

Maximum protrusion means the distance from lens flange to
the glass filter in the camera.
