Configuration of the camera
Guppy PRO Technical Manual V4.0.0
234
Video mode control and status registers for
Format_7
Quadlet offset Format_7 Mode_0
The quadlet offset to the base address for Format_7 Mode_0, which can be
read out at F0F002E0h (according to
Table 112: Frame rate inquiry register
on page 213) gives 003C2000h.
4 x 3C2000h = F08000h so that the base address for the latter ( Table 120:
Format_7 control and status register on page 234) equals

F0000000h + F08000h = F0F08000h.
Quadlet offset Format_7 Mode_1
The quadlet offset to the base address for Format_7 Mode_1, which can be
read out at F0F002E4h (according to
Table 112: Frame rate inquiry register
on page 213) gives 003C2400h.
4 x 003C2400h = F09000h so that the base address for the latter ( Table 120:
Format_7 control and status register on page 234) equals

F0000000h + F09000h = F0F09000h.
Format_7 control and status register (CSR)
Offset Name Description
000h MAX_IMAGE_SIZE_INQ According to IIDC V1.31
004h UNIT_SIZE_INQ According to IIDC V1.31
008h IMAGE_POSITION According to IIDC V1.31
00Ch IMAGE_SIZE According to IIDC V1.31
010h COLOR_CODING_ID See note
014h COLOR_CODING_INQ According to IIDC V1.31
024h

.

.
033h
COLOR_CODING_INQ Vendor Unique Color_Coding

0-127 (ID=128-255)
ID=132 ECCID_MONO12

ID=136 ECCID_RAW12
ID=133 Reserved

ID=134 Reserved

ID=135 Reserved
See Chapter Packed 12-Bit Mode
on page 133.
034h PIXEL_NUMER_INQ According to IIDC V1.31
038h TOTAL_BYTES_HI_INQ According to IIDC V1.31
03Ch TOTAL_BYTES_LO_INQ According to IIDC V1.31
Table 120: Format_7 control and status register
