Introduction
Guppy PRO Technical Manual V4.0.0
14
continued from last page
[continued]
V3.0.2
[continued]
18.05.12
Some minor corrections:
• Guppy PRO cameras have 1 input / 3 outputs (not 2/4) in
Chapter
Pulse-width modulation on page 85
• Corrected frame rates of Guppy PRO F-031 (121 fps),

F-032 (82 fps) and F-146 (17 fps) in Chapter Example 1:
1394b bandwidth of Guppy PRO cameras on page 31
• Guppy PRO F-201B, Format_2, Mode_5: also 7.5 fps
possible: see Chapter
Guppy PRO F-201B / Guppy PRO F-
201C on page 177
New sensors ICX414 and ICX415:
• Guppy PRO F-033 (ICX414):
– Chapter
Guppy PRO F-033B/C on page 42
– Figure 11: Spectral sensitivity of Guppy PRO F-033B on
page 59
– Figure 12: Spectral sensitivity of Guppy PRO F-033C
(without IR cut filter)
on page 59
– New: Table 10: Focal length vs. field of view (Guppy PRO
F-033/046/146) on page 37
– Chapter Video fixed formats Guppy PRO F-033B / Guppy
PRO F-033C on page 167
– Chapter Video Format_7 default modes Guppy PRO F-
033B / Guppy PRO F-033C on page 168
– Chapter Guppy PRO F-033: AOI frame rates on page 191
• Guppy PRO F-046 (ICX415):
– Chapter
Guppy PRO F-046B/C on page 44
– Figure 13: Spectral sensitivity of Guppy PRO F-046B on
page 60
– Figure 14: Spectral sensitivity of Guppy PRO F-046C
(without IR cut filter)
on page 60
– New: Table 10: Focal length vs. field of view (Guppy PRO
F-033/046/146) on page 37
– Chapter Video fixed formats Guppy PRO F-046B / Guppy
PRO F-046C on page 169
– Chapter Video Format_7 default modes Guppy PRO F-
046B / Guppy PRO F-046C on page 170
– Chapter Guppy PRO F-046: AOI frame rates on page 192
to be continued on next page
Version Date Remarks
Table 1: Document history
