Camera interfaces
Guppy PRO Technical Manual V4.0.0
78
Trigger delay
Guppy PRO cameras feature various ways to delay image capture based on
external trigger.
With IIDC V1.31 there is a standard CSR at Register F0F00534/834h to control
a delay up to FFFh x time base value.
The following table explains the inquiry register and the meaning of the var-
ious bits.
Register Name Field Bit Description
0xF0F00534 TRIGGER_DELAY_INQUIRY Presence_Inq [0] Indicates presence of this
feature (read only)
Abs_Control_Inq [1] Capability of control with
absolute value
--- [2] Reserved
One_Push_Inq [3] One-push auto mode (con-
trolled automatically by the
camera once)
Readout_Inq [4] Capability of reading out the
value of this feature
ON_OFF [5] Capability of switching this
feature ON and OFF
Auto_Inq [6] Auto mode (controlled auto-
matically by the camera)
Manual_Inq [7] Manual mode (controlled by
user)
Min_Value [8..19] Minimum value for this fea-
ture
Max_Value [20..31] Maximum value for this fea-
ture
Table 25: Trigger delay inquiry register
