Introduction
Guppy PRO Technical Manual V4.0.0
15
continued from last page
[continued]
V3.0.2
[continued]
18.05.12
Guppy PRO F-503:
• F0M2 (120 fps), F0M5 (120 fps), F1M5 (60 fps) are only
available with electronic rolling shutter (wheras present
in both shutter modes). If using global reset release
shutter the camera runs these modes with half frame
rates only. See Chapter
Guppy PRO F-503B / Guppy PRO F-
503C on page 179.
• Changed range in dB and increment length: Table 45:
Manual gain range of the various Guppy PRO types on
page 106
IR cut filter:
• Changed IR cut filter to
(type Jenofilt 217):
see Figure 6: Approximate spectral transmission of IR cut
filter (may vary slightly by filter lot) (type Hoya C5000) on
page 34
V3.0.3 14.06.12
New frame rates from development:
Guppy PRO F-031
• Guppy PRO F-031: 123 fps instead of 121 fps in F7M0, see
Table 12: Specification Guppy PRO F-031B/C on page 38
• Guppy PRO F-031: 564 fps instead of 563 fps (AOI height
10, Raw12), see
Table 90: Frame rates (fps) of Guppy PRO
F-031 as function of AOI height (pixel) [width=656] on
page 189
• Guppy PRO F-031: 188 fps instead of 199 fps (F7M2,
Mono16), see
Table 69: Video Format_7 default modes
Guppy PRO F-031B / Guppy PRO F-031C on page 164
Guppy PRO F-032
• Guppy PRO F-032: F7M0 (Raw8/Raw12/Raw16/YUV411/
YUV422/Mono8/Mono12/Mono16): 82 fps instead of
79 fps, see
Table 71: Video Format_7 default modes Guppy
PRO F-032B / Guppy PRO F-032C on page 166
Guppy PRO F-033
• Guppy PRO F-033: F7M0 (RGB8): 85 fps instead of 84 fps.
F7M0 (RGB8): 67 fps instead of 66 fps. See
Table 73:
Video Format_7 default modes Guppy PRO F-033B / Guppy
PRO F-033C
on page 168
• Guppy PRO F-033: 85 fps instead of 84 fps. See Chapter
Guppy PRO F-033B/C on page 42
to be continued on next page
Version Date Remarks
Table 1: Document history
