Specifications
Guppy PRO Technical Manual V4.0.0
55
Digital interface IEEE 1394b (IIDC V1.31), 1 x copper connector
Power requirements DC 8 V - 36 V via IEEE 1394 cable or 8-pin HIROSE
Power consumption Typical
3.5 watt (@ 12 V DC)
(full resolution and maximal frame rates)
Dimensions 44.8 mm x 29 mm x 29 mm (L x W x H); incl. connectors, without tripod
and lens
Mass 75 g (without lens) + 5 g filter ring
Operating temperature + 5 °C ... + 45 °C ambient temperature (non-condensing)
Storage temperature - 10 °C ... + 70 °C ambient temperature (non-condensing)
Regulations FCC Class B, CE, RoHS (2002/95/EC)
Standard accessories b/w: protection glass
color: IR cut filter
Optional accessories b/w: IR cut filter, IR pass filter
color: protection glass
On request Host adapter card, power out 6 W (HIROSE)
Software packages API (FirePackage, Fire4Linux)
Note

The design and specifications for the products described
above may change without notice.
Feature Specification
Table 20: Specification Guppy PRO F-503B/C
