Video mode error: These are error modes according IIDC specification:
Vmode_Error_Status register (wrong settings of video mode, format, frame
rate and ISO settings).
Format 7 error: see Format 7 register description of IIDC specification.
Error Code S1
Error Class S2
1 blink 2 blinks 3 blinks 4 blinks 5 blinks 6 blinks 7 blinks
1 blink Video
mode
error Format 7
error 1 Format 7
error 2
2 blinks Camera
class
object Camera
regconst
object Register
mapping Unknown
FPGA type
ID
3 blinks FLASH
class
object Platform
class
object Platform
initializa-
tion Platform
firmware
set Platform
LLC

version
4 blinks FPGA
boot S1
error FPGA
boot S2
error FPGA
boot S3
error FPGA
boot S4
error FPGA
boot S5
error FPGA ver-
sion not
supported
5 blinks Stack
setup
error Stack
start error LLC not
ready
6 blinks
7 blinks
8 blinks No valid
firmware
set

available
Table 22: Error codes
