9
Table 2b. System Dynamic Range at Test Port (dB), Options 219 or 419
Description Specification Typical
Ports 1, 3 1 Ports 2, 4 1 Ports 1, 3 1 Ports 2, 4 1
10 MHz to 50 MHz 93 93 106 104
50 MHz to 100 MHz 103 103 115 114
100 MHz to 500 MHz 117 117 130 129
500 MHz to 3.2 GHz 124 127 130 135
3.2 GHz to 8.5 GHz 127 127 135 134
8.5 GHz to 10 GHz 127 127 135 134
10 GHz to 13.5 GHz 126 125 132 131
13.5 GHz to 16 GHz 126 125 132 131
16 GHz to 20 GHz 124 122 130 127
20 GHz to 24 GHz 118 117 127 124
24 GHz to 26.5 GHz 110 106 121 117
1 Either port can be used as the source port. Any other port can be used as the receiver port.
Table 2c. System Dynamic Range at Test Port (dB), Option 224
Description Specification Typical
Source 2 Out 1 Source 2 Out 2 Source 2 Out 1 Source 2 Out 2
10 MHz to 50 MHz 98 93 108 105
50 MHz to 100 MHz 108 107 117 116
100 MHz to 500 MHz 122 121 132 131
500 MHz to 3.2 GHz 128 128 134 136
3.2 GHz to 8.5 GHz 132 132 139 139
8.5 GHz to 10 GHz 132 132 139 139
10 GHz to 13.5 GHz 130 130 138 137
13.5 GHz to 16 GHz 130 130 138 137
16 GHz to 20 GHz 129 127 136 134
20 GHz to 24 GHz 123 122 133 132
24 GHz to 26.5 GHz 114 112 127 124
