52
1 In Filtered Mode, the signal path goes through filters to minimize harmonics below 3.2 GHz. In Hi Power Mode, the
signal bypasses the filters to maximize output power.
Table 41b. Reference Receiver Inputs and Reference Source Outputs (dBm) - Typical
(RCVR R2, R3, R4 IN, REF 2, 3, 4 SOURCE OUT) @ Max Specified Output Power
Description Option 400
Options 200,
400
Option 419
Options 219,
419
RCVR R3
IN,
REF 3
SOURCE
OUT
RCVR R3
IN,
REF 3
SOURCE
OUT
RCVR R2,
R4 IN,
REF 2, 4
SOURCE OUT
RCVR R3
IN,
REF 3
SOURCE
OUT
RCVR R3
IN,
REF 3
SOURCE
OUT
RCVR R2,
R4 IN,
REF 2, 4
SOURCE OUT
Filtered
Mode 1
Hi Power
Mode 1
Filtered
Mode 1
Hi Power
Mode 1
10 MHz to 50 MHz -6 -1 -1 -6 -1 -1
50 MHz to 500 MHz -4 -1 -1 -4 -1 -1
500 MHz to 3.2 GHz -4 -4 0 -3 -3 -1
3.2 GHz to 8.5 GHz 0 0 0 1 1 0
8.5 GHz to 10 GHz 0 0 0 1 1 0
10 GHz to 13.5 GHz 1 1 0 1 1 1
13.5 GHZ to 16 GHz 1 1 0 1 1 1
16 GHZ to 20 GHz 1 1 -3 0 0 -3
20 GHZ to 24 GHz 0 0 -6 -1 -1 -4
24 GHZ to 26.5 GHz -8 -8 -12 -7 -7 -13
1 In Filtered Mode, the signal path goes through filters to minimize harmonics below 3.2 GHz. In Hi Power Mode, the
signal bypasses the filters to maximize output power.
Table 41c. Reference Receiver Inputs and Reference Source Outputs (dBm) - Typical
(RCVR R2, R3, R4 IN, REF 2, 3, 4 SOURCE OUT) @ Max Specified Output Power
Description Option 423 Options 224, 423
RCVR R3 IN,
REF 3 SOURCE OUT
RCVR R3 IN,
REF 3 SOURCE OUT
RCVR R2, R4 IN,
REF 2, 4 SOURCE OUT
Filtered Mode 1 Hi Power Mode 1
10 MHz to 50 MHz -7 -4 -1
50 MHz to 500 MHz -6 -4 -1
500 MHz to 3.2 GHz -5 -3 -1
3.2 GHz to 8.5 GHz 1 1 0
8.5 GHz to 10 GHz 1 1 0
