Table 9f. Maximum Leveled Power (dBm), Option 224
Description Specification Typical
Source 2 Out 1
Source 2
Out 2
Source 2 Out 1
Source 2
Out 2
Filt. Mode 2 Hi Pwr Mode 2 Filt. Mode 2 Hi Pwr Mode 2
10 MHz to 50 MHz 9 18 13 12 21 18
50 MHz to 500 MHz 11 18 17 13 22 21
500 MHz to 3.2 GHz 10 14 14 13 17 19
3.2 GHz to 8.5 GHz 18 18 18 22 22 22
8.5 GHz to 10 GHz 18 18 18 22 22 22
10 GHz to 13.5 GHz 16 16 16 21 21 20
13.5 GHz to 16 GHz 16 16 16 21 21 20
16 GHz to 20 GHz 15 15 13 19 19 17
20 GHz to 24 GHz 13 13 12 18 18 17
24 GHz to 26.5 GHz 7 7 5 14 14 11
1 In Filtered Mode, the signal path goes through filters to minimize harmonics below 3.2 GHz. In Hi Power Mode, the
signal bypasses the filters to maximize output power.
Table 9g. Maximum Leveled Power (dB), Options 224 or 423 with 029 1
Description Specification Typical
Port 1 Ports 2 Port 1 Ports 2
Filt. Mode 2 Hi Pwr Mode 2 Filt. Mode 2 Hi Pwr Mode 2
10 MHz to 50 MHz 6 12 13 8 18 17
50 MHz to 500 MHz 8 13 13 11 20 20
500 MHz to 3.2 GHz 8 10 12 11 13 16
3.2 GHz to 8.5 GHz 13 13 13 19 19 17
8.5 GHz to 10 GHz 13 13 13 19 19 17
10 GHz to 13.5 GHz 12 12 10 15 15 14
13.5 GHz to 16 GHz 12 12 10 15 15 14
16 GHz to 20 GHz 10 10 6 13 13 9
20 GHz to 24 GHz 6 6 4 11 11 8
24 GHz to 26.5 GHz 0 0 -2 8 8 4
1 Option 029 affects port 1 and port 2 maximum leveled power. Refer to Table 9c for other ports.
2 In Filtered Mode, the signal path goes through filters to minimize harmonics below 3.2 GHz. In Hi Power Mode, the
signal bypasses the filters to maximize output power.
