Noise Receiver Input (Option 029 only)
Table 25. Noise Receiver Bandwidth
Description Bandwidth
10 MHz to 25 MHz 800 kHz, 2 MHz
25 MHz to 60 MHz 800 kHz, 2/4 MHz
60 MHz to 150 MHz 800 kHz, 2/4/8 MHz 1
150 MHz to 26.5 GHz 800 kHz, 2/4/8/24 MHz 1
1 8 and 24 MHz bandwidths are available only with calibration using noise source.
Table 26. Receiver Noise Figure (dB), Port 2, at All BW, High Gain Setting
Description Specification Typical
10 MHz to 200 MHz 9.0 --
200 MHz to 2 GHz 12.0 --
2 GHz to 8.5 GHz 14.5 --
8.5 GHz to 13.5 GHz 14.5 --
13.5 GHz to 16 GHz 14.5 --
16 GHz to 26.5 GHz 17.0 1 --
1 Degraded by 1.5 dB with 24 MHz BW.
Table 27. Noise Figure Trace Noise 1 (dB rms) at 4 MHz BW
Frequency Specification Typical
Low Gain
Setting
Medium Gain
Setting
High Gain
Setting
Low Gain
Setting
Medium Gain
Setting
High Gain
Setting
10 MHz to 15 MHz 0.30 0.30 0.10 0.15 0.15 0.07
15 MHz to 3 GHz 0.10 0.10 0.10 0.07 0.07 0.07
3 GHz to 8.5 GHz 0.11 0.10 0.10 0.07 0.07 0.07
8.5 GHz to 13.5 GHz 0.11 0.10 0.10 0.07 0.07 0.07
13.5 GHz to 26.5 GHz 0.11 0.10 0.10 0.07 0.07 0.07
1 Trace noise magnitude performance on noise figure trace or sometime called noise jitter, 201 points, 1 noise average,
port 2 terminated. May typically be degraded at frequencies below 500 MHz due to spurious noise receiver residuals.
