Ordering guide for PNA series
Network analyzers
Options
To add options to a product, order the corresponding item number.
Description For E8362C For E8363C For E8364C For E8361C Additional
item number item number item number item number information
Test set
Option 014 • Configurable test set E8362C-014 E8363C-014 E8364C-014 E8361C-014
Power configuration
Option UNL • Extended power range and bias-tees E8362C-UNL E8363C-UNL E8364C-UNL E8361C-UNL E8361C only,
requires 014
Option 016 • Add receiver attenuators E8362C-016 E8363C-016 E8364C-016 E8361C-016 E8361C only,
requires 014
and UNL
Non-linear measurements
Option 080 • Frequency offset E8362C-080 E8363C-080 E8364C-080 E8361C-080 Requires 014
Option 081 • Reference receiver switch E8362C-081 E8363C-081 E8364C-081 E8361C-081 Requires 014, 080
Option 083 • Frequency-converter E8362C-083 E8363C-083 E8364C-083 E8361C-083 Requires 014, 080,
measurement application and 081
Option H11 • IF access (for antenna and E8362C-H11 E8363C-H11 E8364C-H11 E8361C-H11 Requires 014, 080,
pulsed-RF measurements) 081, and UNL
Option H08 • Pulsed-RF measurement capability E8362C-H08 E8363C-H08 E8364C-H08 E8361C-H08
Measurement features
Option 010 • Time-domain capability E8362C-010 E8363C-010 E8364C-010 E8361C-010
Option 550 2 • 4-port measurement application E8362C-550 E8363C-550 E8364C-550 E8361C-550
Option 551 2 • N-port measurements E8362C-551 E8363C-551 E8364C-551 E8361C-551
Accessories
Option 1CM • Rack mount kit without handles E8362C-1CM E8363C-1CM E8364C-1CM E8361C-1CM
Option 1CP • Rack mount kit with handles E8362C-1CP E8363C-1CP E8364C-1CP E8361C-1CP
N4688A • USB CD R/W drive N4688A N4688A N4688A N4688A
N4689A • USB Hub N4689A N4689A N4689A N4689A
Calibration documentation
Option 1A7 • ISO 17025 compliant calibration E8362C-1A7 E8363C-1A7 E8364C-1A7 Available soon
Option UK6 • Commercial calibration certificate E8362C-UK6 E8363C-UK6 E8364C-UK6 E8361C-UK6
with test data
Option A6J • ANSI Z540 compliant calibration E8362C-A6J E8363C-A6J E8364C-A6J E8361C-A6J
Cal SW for self-maintainers
Option 897 • Cal software for Agilent inclusive cal E8362C-897 E8363C-897 E8364C-897 E8361C-897
Option 898 • Cal software for standards compliant cal E8362C-898 E8363C-898 E8364C-898 E8361C-898
Warranty and service
One, three and five year warranty and service plans are available at the time of instrument purchase. The N5250C microwave 110 GHz
system carries a full one-year on-site warranty (where available).
Calibration
Three and five year calibration plans are available at time of instrument purchase.
1. Not all models are available in all countries.
2. External test set must be connected.
This guide is intended to assist you in the ordering pro-
cess. For detailed ordering information, refer to the PNA
Series Microwave Network Analyzer Configuration
Guide (literature number 5989-7606EN). PNA Series microwave network analyzers 1
E8362C 10 MHz to 20 GHz
E8363C 10 MHz to 40 GHz
E8364C 10 MHz to 50 GHz
E8361C 10 MHz to 67 GHz
