14
1. Source output performance on port 1 only. Port 2 output performance is typical,
except for power level accuracy which is characteristic.
E8362/3/4C
Test port output
continued
Description Specification Supplemental information
Phase noise (1 kHz offset from center frequency, nominal power at test port)
10 MHz to 10 GHz -60 dBc typical
10 to 20 GHz -55 dBc typical
20 to 50 GHz -50 dBc typical
Phase noise (1 kHz offset from center frequency, nominal power at test port) – Option 080 enabled
10 MHz to 10 GHz -60 dBc typical
10 to 20 GHz -60 dBc typical
20 to 50 GHz -50 dBc typical
Phase noise (10 kHz offset from center frequency, nominal power at test port)
10 to 45 MHz -70 dBc typical
45 MHz to 10 GHz -70 dBc typical
10 to 20 GHz -65 dBc typical
20 to 40 GHz -55 dBc typical
40 to 50 GHz -55 dBc typical
Phase noise (10 kHz offset from center frequency, nominal power at test port) – Option 080 enabled
10 to 45 MHz -70 dBc typical
45 MHz to 10 GHz -70 dBc typical
10 to 20 GHz -65 dBc typical
20 to 40 GHz -55 dBc typical
40 to 50 GHz -55 dBc typical
Phase noise (100 kHz offset from center frequency, nominal power at test port)
10 MHz to 10 GHz -60 dBc typical
10 to 20 GHz -55 dBc typical
20 to 50 GHz -50 dBc typical
Phase noise (100 kHz offset from center frequency, nominal power at test port) – Option 080 enabled
10 MHz to 10 GHz -75 dBc typical
10 to 20 GHz -70 dBc typical
20 to 50 GHz -65 dBc typical
Phase noise (1 MHz offset from center frequency, nominal power at test port)
10 MHz to 10 GHz -106 dBc typical
10 to 20 GHz -103 dBc typical
20 to 50 GHz -90 dBc typical
Phase noise (1 MHz offset from center frequency, nominal power at test port) – Option 080 enabled
10 MHz to 10 GHz -103 dBc typical
10 to 20 GHz -97 dBc typical
20 to 50 GHz -85 dBc typical
Harmonics (2nd or 3rd) -23 dBc typical, in power range 0
Non-harmonic spurious (at nominal output power)
10 to 45 MHz -50 dBc typical, for offset
frequency > 1 kHz
45 MHz to 20 GHz -50 dBc typical, for offset
frequency > 1 kHz
20 to 40 GHz -30 dBc typical, for offset
frequency > 1 kHz
40 to 50 GHz -30 dBc typical, for offset
frequency > 1 kHz
