52
Frequency Converter Application (Option 083) cycle time for
fixed-IF measurements (s)1
Number of points
101 201 401
Stimulus start = 1 GHz, stop = 11 GHz, IFBW = 35 kHz
Response = 70 MHz, trace = SC21, cal = SMC_2P
Hardware trigger 8.5 17 34
Software trigger 31 62 124
Data transfer time (ms)2
Number of points
201 401 1601 16,001
SCPI over GPIB
(program executed on external PC)
32-bit floating point
7 12 43 435
64-bit floating point 12 22 84 856
ASCII 64 124 489 5054
SCPI (program executed in the analyzer)
32-bit floating point
1 2 3 30
64-bit floating point 2 2 4 40
ASCII 29 56 222 2220
COM (program executed in the analyzer)
32-bit floating point
1 1 1 6
Variant type 1 2 6 68
DCOM over LAN
(program executed on external PC)
32-bit floating point
1 1 2 121
Variant type 3 6 19 939
1. Typical performance, using an Agilent PSG (E8257D) signal generator for the external LO source.
2. Typical performance.
