24
E8361C
Corrected system performance with 1.85 mm connectors continued
Description Specification (dB)
30 to 40 GHz 40 to 50 GHz 50 to 60 GHz 60 to 67 GHz
Directivity 44 42 41 38
Source match
34 33 30 27
Load match 33 32 29 26
Reflection tracking ±0.060 (+0.02/°C) ±0.070 (+0.02/°C) ±0.080 (+0.02/°C) ±0.090 (+0.03/°C)
Transmission tracking ±0.082 (+0.02/°C) ±0.097 (+0.02/°C) ±0.112 (+0.02/°C) ±0.144 (+0.03/°C)
Transmission uncertainty (specifications)
Reflection uncertainty (specifications)
Magnitude
0.01
0.1
1
10
-90 -80 -70 -60 -50 -40 -30 -20 -10 0 10
Transmission coefficient (dB)
E8361C fully optioned 1 full two port cal using N4694A
30 to 40 GHz
40 to 50 GHz
50 to 60 GHz
60 to 67 GHz
S11 = S22 = 0
Source power = -20 dBm
Uncertainty (dB)
Phase
0.1
1
10
100
-90 -80 -70 -60 -50 -40 -30 -20 -10 0 10
Transmission coefficient (dB)
E8361C fully optioned 1 full two port cal using N4694A
30 to 40 GHz
40 to 50 GHz
50 to 60 GHz
60 to 67 GHz
S11 = S22 = 0
Source power = -20 dBm
Uncertainty (degrees)
Magnitude
0
0.01
0.02
0.03
0.04
0.05
0 0.2 0.4 0.6 0.8 1
Reflection coefficient (linear)
E8361C fully optioned 1 with N4694A
30 to 40 GHz
40 to 50 GHz
50 to 60 GHz
60 to 67 GHz
S21 = S12 = 0
Source power = -20 dBm
Uncertainty (linear)
Phase
0
2
4
6
8
10
0 0.2 0.4 0.6 0.8 1
Reflection coefficient (linear)
E8361C fully optioned 1 with N4694A
30 to 40 GHz
40 to 50 GHz
50 to 60 GHz
60 to 67 GHz
S21 = S12 = 0
Source power = -20 dBm
Uncertainty (deg)
Fully optioned (E8361C with options 014/UNL/080/081/016)
Applies to E8361C PNA Series analyzer, N4694A
(1.85 mm) ECal electronic calibration module, 85133F
flexible test port cable set, and a full two-port calibration.
(Specifications apply over environmental temperature
of 23 °C ±3 °C, with less than 1 °C deviation from
calibration temperature.)
1. Configurable Test Set, Extended Power Range and Bias-Tees, Receiver Attenuators, Frequency Offset Mode, and
Reference Channel Transfer Switch (Option 014, UNL, 016, 080 and 081).
