133 0700015-J0 Rev B
Table T — CXC Modbus PDU address definition for function code 0x02 (read discrete inputs)
PDU Address Variable Name Variable Description
Response
Data
Format
0x0141 Alarm1_In_Alarm_Table_6_Status_Bit Temp Sensor 1 Fail BINARY
0x0142 Alarm2_In_Alarm_Table_6_Status_Bit Temp Sensor 2 Fail BINARY
0x0143 Alarm3_In_Alarm_Table_6_Status_Bit Temp Sensor 3 Fail BINARY
0x0144 Alarm4_In_Alarm_Table_6_Status_Bit Temp Sensor 4 Fail BINARY
0x0145 Alarm5_In_Alarm_Table_6_Status_Bit TC Sensor Fail BINARY
0x0181 Alarm1_In_Alarm_Table_7_Status_Bit Custom 1 BINARY
0x0182 Alarm2_In_Alarm_Table_7_Status_Bit Custom 2 BINARY
0x0183 Alarm3_In_Alarm_Table_7_Status_Bit Custom 3 BINARY
0x0184 Alarm4_In_Alarm_Table_7_Status_Bit Custom 4 BINARY
0x0185 Alarm5_In_Alarm_Table_7_Status_Bit Custom 5 BINARY
0x0186 Alarm6_In_Alarm_Table_7_Status_Bit Custom 6 BINARY
0x0187 Alarm7_In_Alarm_Table_7_Status_Bit Custom 7 BINARY
0x0188 Alarm8_In_Alarm_Table_7_Status_Bit Custom 8 BINARY
0x0189 Alarm9_In_Alarm_Table_7_Status_Bit Custom 9 BINARY
0x018A Alarm10_In_Alarm_Table_7_Status_Bit Custom 10 BINARY
0x018B Alarm11_In_Alarm_Table_7_Status_Bit Custom 11 BINARY
0x018C Alarm12_In_Alarm_Table_7_Status_Bit Custom 12 BINARY
0x018D Alarm13_In_Alarm_Table_7_Status_Bit Custom 13 BINARY
0x018E Alarm14_In_Alarm_Table_7_Status_Bit Custom 14 BINARY
0x018F Alarm15_In_Alarm_Table_7_Status_Bit Custom 15 BINARY
0x0190 Alarm16_In_Alarm_Table_7_Status_Bit Custom 16 BINARY
0x0191 Alarm17_In_Alarm_Table_7_Status_Bit Custom 17 BINARY
0x0192 Alarm18_In_Alarm_Table_7_Status_Bit Custom 18 BINARY
0x0193 Alarm19_In_Alarm_Table_7_Status_Bit Custom 19 BINARY
0x0194 Alarm20_In_Alarm_Table_7_Status_Bit Custom 20 BINARY
0x01C1 Alarm1_In_Alarm_Table_8_Status_Bit Real Time Clock Error BINARY
0x01C2 Alarm2_In_Alarm_Table_8_Status_Bit Invalid Device Firmware BINARY
0x01C3 Alarm3_In_Alarm_Table_8_Status_Bit Ground Fault Detected BINARY
0x01C4 Alarm4_In_Alarm_Table_8_Status_Bit Improper CXC Shutdown BINARY
0x01C5 Alarm5_In_Alarm_Table_8_Status_Bit Invalid Charge Voltage BINARY
0x01C6 Alarm6_In_Alarm_Table_8_Status_Bit System Major BINARY
0x01C7 Alarm7_In_Alarm_Table_8_Status_Bit System Minor BINARY
0x0201 Alarm1_In_Alarm_Table_9_Status_Bit LVD 1 BINARY
0x0202 Alarm2_In_Alarm_Table_9_Status_Bit LVD 2 BINARY
0x0203 Alarm3_In_Alarm_Table_9_Status_Bit LVD 3 BINARY
0x0204 Alarm4_In_Alarm_Table_9_Status_Bit LVD 4 BINARY
0x0205 Alarm5_In_Alarm_Table_9_Status_Bit LVD 5 BINARY
0x0206 Alarm6_In_Alarm_Table_9_Status_Bit LVD 6 BINARY
0x0207 Alarm7_In_Alarm_Table_9_Status_Bit LVD 7 BINARY
