Table O — Signals menu defaults
Submenu Item
Programmable Range
Default Setting
Load Voltage (V1)
Decimal precision: 0-3
2
Load Current (I1)
Decimal precision: 0-3
1
Battery Voltage (V2)
Decimal precision: 0-3
2
Battery Current (I2)
Decimal precision: 0-3
1
AC Mains
Decimal precision: 0-3
1
Battery Temperature
Decimal precision: 0-3
2
Temp Comp Sensor 1
Enable/Disable
Disable
Temp Comp Sensor 2
Enable/Disable
Disable
Temp Comp Sensor 3 (GP1)
Enable/Disable
Disable
Temp Comp Sensor 4 (GP2)
Enable/Disable
Disable
Battery Runtime
Decimal precision: 0-3
2
Battery Capacity
Decimal precision: 0-3
1
Battery Depth of Discharge (DOD)
Decimal precision: 0-3
1
Analog Inputs
See 6.6.1.1
N/A
Digital Inputs (1-8)
High/Low
Low
Rectifier Signals
See Menu Tree
N/A
Custom Signals (1-20)
Decimal precision: 0-3
2
Signal Units
A, V, W, ºC (ºF)
V
Set by SNMP
Enabled/Disabled
Disabled
Set by Equation
Enabled/Disabled
Enabled
