Alpha Technologies Cordex Controller Ver.3.1x User Manual
Page 129
127
0700015-J0 Rev B
Table Q — Inverter Parameters
Submenu Item
Default Setting
Units
Max power (pc of nominal power)
150
%
Max Overload Duration
15
s
Synchronisation Tracking Speed
0
Remote OFF disable ACin Power
0
Negative Power (0 : OFF 1 : ON)
1
External Clock (0 : NO 1 : YES)
0
OUT 1 : phase shift
0
deg
OUT 1 : Nominal Output Voltage
120.0
V
OUT 2 : phase shift
120
deg
OUT 2 : Nominal Output Voltage
120.0
V
OUT 3 : phase shift
240
deg
OUT 3 : Nominal Output Voltage
120.0
V
OUT 4 : phase shift
0
deg
OUT 4 : Nominal Output Voltage
120.0
V
OUT 5 : phase shift
0
deg
OUT 5 : Nominal Output Voltage
120.0
V
OUT 6 : phase shift
0
deg
OUT 6 : Nominal Output Voltage
120.0
V
OUT 7 : phase shift
0
deg
OUT 7 : Nominal Output Voltage
120.0
V
OUT 8 : phase shift
0
deg
OUT 8 : Nominal Output Voltage
120.0
V
DC 1 : Vdc_in Low Start
49.0
V
DC 1 : Vdc_in Low Transfer
42.0
V
DC 1 : Vdc_in Low Stop
42.0
V
DC 1 : Vdc_in High Start
61.0
V
DC 1 : Vdc_in High Transfer
62.0
V
DC 1 : Vdc_in High Stop
62.0
V
DC 2 : Vdc_in Low Start
49.0
V
DC 2 : Vdc_in Low Transfer
42.0
V
DC 2 : Vdc_in Low Stop
42.0
V
DC 2 : Vdc_in High Start
61.0
V
DC 2 : Vdc_in High Transfer
62.0
V
