A-21 VTG 400D/400 DVI • Appendix
VTG 400D/400 DVI Video Output Scan Rate Table
Stereographics
Rates
Super Hi Res
Rates
16:9 Hi Res
Rates
Supported
Formats
Pixel x
Line
Horiz
Rate
(kHz)
Vert
Rate
(Hz)
Output Type Supported
Formats
Pixel x
Line
Horiz
Rate
(kHz)
Vert
Rate
(Hz)
Output Type
Stereographics VGA
SGI stereo
SGI stereo
SGI stereo
SGI stereo
SGI stereo
SGI stereo
SGI stereo
SGI stereo
640 x 222
640 x 480
640 x 512
1024 x 768
1024 x 768
1120 x 840
1280 x 1024
1280 x 1024
1280 x 492
31.5
60.84
65.28
96.84
77.47
84.38
124.60
131.16
63.96
120
120
120
120
96
96
114
120
120
RGB, DVI
RGB, DVI
RGB, DVI
RGB, DVI
RGB, DVI
RGB, DVI
RGB
RGB
RGB, DVI
16:9
16:9
16:9
16:9
16:9
WXGA1
WXGA2
WXGA3
WXGA4
WXGA5
WXGA6
WXGA7
WXGA8
WSXGA
WSXGA+1
WSXGA+2
1080p PC
WUXGA1
WUXGA2
WQXGA
848 x 480
852 x 480
960 x 540
1024 x 576
1024 x 576
1280 x 768
1280 x 768
1280 x 768
1280 x 800
1360 x 765
1360 x 768
1365 x 768
1366 x 768
1440 x 900
1680 x 1050
1680 x 1050
1920 x 1080
1920 x 1200
1920 x 1200
2560 x 1600
31.02
31.8
33.78
44.04
52.85
45.11
48.0
47.77
49.7
47.7
47.72
47.7
47.8
55.94
64.67
65.29
67.2
74.52
74.6
99.46
60
60
60
60
72
56
60
60
60
60
60
60
60
60
60
60
60
60
60
60
RGB, DVI
RGB, DVI
RGB, DVI
RGB, DVI
RGB, DVI
RGB, DVI
RGB, DVI
RGB, DVI
RGB, DVI
RGB, DVI
RGB, DVI
RGB, DVI
RGB, DVI
RGB, DVI
RGB, DVI
RGB, DVI
RGB
RGB, DVI
RGB
RGB
PC Rates
VGA 640 x 480 31.5 60 RGB, DVI
VESA 2 (VGA) 640 x 480 37.9 72 RGB, DVI
VESA1 (SVGA) 800 x 600 35.2 56 RGB, DVI
VESA5 (SVGA) 800 x 600 37.9 60 RGB, DVI
VESA6 (SVGA) 800 x 600 48.1 72 RGB, DVI
VESA3 (XGA) 1024 x 768 48.4 60 RGB, DVI
VESA4 (XGA) 1024 x 768 56.4 70 RGB, DVI
XGA5 1024 x 768 57 70 RGB, DVI
VESA8 (XGA) 1024 x 768 60 75 RGB, DVI
VESA9 (XGA) 1024 x 768 68.7 85 RGB, DVI
VESA10 (XGA+) 1152 x 864 67.5 75 RGB, DVI
1280 x 960 1280 x 960 60 60 RGB, DVI
1280 x 960 1280 x 960 70 70 RGB, DVI
1280 x 960 1280 x 960 75 75 RGB, DVI
VESA11 (SXGA) 1280 x 1024 64 60 RGB, DVI
VESA12 (SXGA) 1280 x 1024 91.1 85 RGB, DVI
SXGA+1 1400 x 1050 63.9 60 RGB, DVI
SXGA+2 1400 x 1050 65.32 60 RGB, DVI
VESA13 (UXGA) 1600 x 1200 75 60 RGB, DVI
VESA14 (UXGA) 1600 x 1200 87.5 70 RGB
VESA15 (UXGA) 1600 x 1200 106.3 85 RGB
QXGA1 2048 x 1536 99.46 60 RGB
QXGA2 2048 x 1536 115 71.8 RGB
LCoS1 1360 x 1024 80 75.1 RGB, DVI
LCoS2 1365 x 1024 65.2 60 RGB, DVI
Workstation
Rates
SGI 640 x 480 31.5 60 RGB, DVI
SGI 640 x 512 32.22 60 RGB, DVI
SGI 800 x 600 37.8 60 RGB, DVI
SGI 960 x 680 42.84 60 RGB, DVI
SGI 960 x 620 39.06 60 RGB, DVI
SGI 1024 x 768 48.36 60 RGB, DVI
SGI 1024 x 768 40.3 50 RGB, DVI
SGI 1200 x 900 68.04 72 RGB, DVI
SGI 1280 x 1024 53.25 50 RGB, DVI
SGI 1280 x 1024 63.9 60 RGB, DVI
SGI 1280 x 1024 76.68 72 RGB, DVI
SGI 1500 x 1200 75.6 60 RGB, DVI
SGI 1600 x 1024 63.38 60 RGB, DVI
SGI 1600 x 1200 75 60 RGB, DVI
SGI 1760 x 1100 71.04 60 RGB
SGI 1920 x 1035 33.75 60/30 RGB, DVI
SGI 1920 x 1080 33.72 60/30 RGB, DVI
SGI 1920 x 1080 70.31 60 RGB
SGI 1920 x 1080 84.37 72 RGB
SGI 1920 x 1200 77.52 60 RGB
SGI 1920 x 1200 85.27 66 RGB
SGI 2048 x 1120 83.45 72 RGB
Sun 1152 x 900 61.8 66 RGB, DVI
Sun 1152 x 900 71.7 76 RGB, DVI
Sun 1280 x 1024 81 76 RGB, DVI
Sun 1600 x 1280 89.3 67 RGB
Sun 1920 x 1080 84.4 72 RGB
Sun 1920 x 1200 87.2 70 RGB
Sun 1920 x 1200 93.6 75 RGB
HDTV
Rates
480p
576p
720p
720p
720p
720p
720p
720p
1080i
1080i
1080i
1080p
1080p
1080p
1080p
1080p
1080p
1080p (24PsF)
1080p (24PsF)
1035i
1035i
720 x 483
720 x 576
1280 x 720
1280 x 720
1280 x 720
1280 x 720
1280 x 720
1280 x 720
1920 x 1080
1920 x 1080
1920 x 1080
1920 x 1080
1920 x 1080
1920 x 1080
1920 x 1080
1920 x 1080
1920 x 1080
1920 x 1080
1920 x 1080
1920 x 1035
1920 x 1035
31.42
31.25
44.96
45
37.5
22.5
22.48
18.75
33.72
33.75
28.13
67.5
33.75
33.72
56.25
28.13
27
27
26.97
33.75
33.72
59.94
50
59.94
60
50
29.97
30
25
29.97
30
25
60
30
29.97
50
25
24
24
23.98
30
29.97
YUV, RGB, DVI
YUV, RGB, DVI
YUV, RGB, HDSDI, DVI
YUV, RGB, HDSDI, DVI
YUV, RGB, HDSDI, DVI
YUV, RGB, HDSDI, DVI
YUV, RGB, HDSDI, DVI
YUV, RGB, HDSDI, DVI
YUV, RGB, HDSDI, DVI
YUV, RGB, HDSDI, DVI
YUV, RGB, HDSDI, DVI
YUV, RGB, DVI
YUV, RGB, HDSDI, DVI
YUV, RGB, HDSDI, DVI
YUV, RGB, DVI
YUV, RGB, HDSDI, DVI
YUV, RGB, HDSDI, DVI
YUV, RGB, HDSDI, DVI
YUV, RGB, HDSDI, DVI
YUV, RGB, HDSDI, DVI
YUV, RGB, HDSDI, DVI
Video
Rates
NTSC
NTSC 0 IRE (JPN)
PAL I
PAL B, G, H
PAL N
720 x 485
720 x 485
720 x 575
720 x 575
720 x 575
15.7
15.7
15.6
15.6
15.6
60/30
60/30
50/25
50/25
50/25
VID, Y/C, YUV, RGB, SDI
VID, Y/C, YUV, RGB, SDI
VID, Y/C, YUV, RGB, SDI
VID, Y/C, YUV, RGB, SDI
VID, Y/C, YUV, RGB, SDI
Cornerstone 1600 x 1800 105 76 RGB
Extron 1280 x 1024 92 86.8 RGB, DVI
Extron 1600 x 1280 95 70.9 RGB
Extron 1800 x 1440 105 70 RGB
