Serial Communication, cont’d
VTG 400D/400 DVI • Serial Communication
3-18
Enter the appropriate information in the above screen, including the horizontal
and vertical active video information, rate name and resolution. Select the Apply
button to add the new rate.
The VTG 400 DVI only outputs custom rates with a pixel clock of less than
165 MHz
Click the
Print button to print the screen image. The information is sent to
Internet Explorer where it can be viewed and printed.
View button
— Selecting this button allows you to view the selected rate’s
details. If the selected rate is from the Custom Rates group, the values can
be edited and applied. See the following screen example.
