3-11 VTG 400D/400 DVI • Serial Communication
Control Software for Windows
The included Extron VTG 400/400D/400 DVI Control Program for Windows
offers another way to control the VTG via RS-232 connection in addition to the
Simple Instruction Set commands. The control program’s graphical interface
includes the same functions as those on the video test generator’s top panel and
some additional features that are only available through the Windows-based
software.
The control software is compatible with Windows 98, Windows NT, Windows
2000, and Windows XP. VTG 400/400D/400 DVI Control Program updates can
be downloaded from the Extron Web site:
http://www.extron.com
.
Installing the software
The control program is contained on a disk that is delivered with your VTG. To
use the software, you must install the program on your PC. Follow these steps:
1. Insert the disk into your disk drive. The disk should start automatically. If
it does not, open your Windows Explorer and double-click LAUNCH.EXE
on the disk drive to start it.
2. On the Software Products Disk screen (see below), click the
Software
button.
Link to the installation software on the VTG 400/400D/400 DVI disk
