VTG 400D/400 DVI • Serial Communication

List rates

All rates

L/l

X4

...

X4

List VTG scan rates (all rates
returned).

By range

X24

L/

X24

l

X4

...

X4

List scan rates for range

X24

.

Set test pattern

Specific pattern

X2

J/

X2

j

Tst

X2

Select pattern

X2

.

Increment up

+J/+j

Tst

X2

Select next higher pattern.

Increment down

-J/-j

Tst

X2

Select next lower pattern.

View

J/j

X2

View current setting.

Invert test pattern / Special function

(blue mode for SMPTE color bars and pause for CTF)

Invert current test pattern

1*21#

Inv1

Invert or activate the special
function for the current test
pattern.

Return to normal test pattern

0*21#

Inv0

Disables special function for
selected pattern.

View status

21#

1

/0

= on/off

View current setting.

Set output rate

Specific value

X3

*

X24

=

Rte

X3

*

X24

Select rate

X3

from range

X24

.

Increment up

+=

Rte

X3

*

X24

Select next higher rate in
current range.

Increment down

-=

Rte

X3

*

X24

Select next lower rate in
current range.

View

=

X3

*

X24

View current setting.

Set screensaver timeout interval

Specific value

X5

*1#

Tmo

X5

Set timeout interval.

Increment up

+1#

Tmo

X5

Select next higher interval.

Increment down

-1#

Tmo

X5

Select next lower interval.

View

1 #

X5

View current setting.

Set test pattern autosequence

Specific value

X6

*2#

Asq

X6

Set autosequence interval.

Increment up

+2#

Asq

X6

Select next higher interval.

Increment down

-2#

Asq

X6

Select next lower interval.

View

2 #

X6

View current setting.

Set audio signal type

Set signal type

X7

*3#

Ast

X7

Select audio signal type

X7

.

View

3 #

X7

View current setting.

Set audio tone frequency

(applies to sine, square wave, and burst signals only)

Specific value

X14

*4#

Afq

X14

Set tone frequency to

X14

.

Increment up

+4#

Afq

X14

Select next higher frequency.

Increment down

-4#

Afq

X14

Select next lower frequency.

View

4 #

X14

View current setting.

Set audio sweep speed

(applies to audio sweep signal only)

Set sweep speed

X15

*5#

Sws

X15

Set audio sweep speed to

X15

.

Command/response table for SIS commands (continued)

Command

ASCII Command Response

Additional description

(host to VTG)

(VTG to host)

(Continued)
