2-19

VTG 400D/400 DVI • Installation and Operation

Button Lock
Enabled!

O

Button Lock
Disabled!

O

SIGNAL

TYPE

TEST

PATTERN

Simultaneously press both buttons for

two seconds to enable button lock mode

Simultaneously press both buttons for

two seconds to disable button lock mode

Power

on

RES: VGA 640x480
FRQ: 31.50kHz 60.00Hz
PAT: Fine Crosshatch
SIG: Pink noise FRQ: N/A
LEV: -10 dBu 245mV

VTG 400

VIDEO TEST GENERATOR
60-564-01 Ver. 1.00

3 sec.

SIGNAL

TYPE

TEST

PATTERN

Button lock mode
