VTG 400D/400 DVI • Serial Communication

3-2

Serial Communication

The VTG can be remotely controlled via a host computer or other device (such as

a control system) attached to the rear panel RS-232 connector. The control device

(host) can use either the Extron Simple Instruction Set (SIS

) commands or the

graphical control program for Windows

®

.

The VTG uses a protocol of 9600 baud, 1 stop bit, no parity, and no flow control.
The rear panel RS-232 9-pin D connector has the following pin assignments:

Pin RS-232

function Description

1 – No

connection

2

Tx

Transmit data

3

Rx

Receive data

4

No

connection

5

Gnd

Sign

al ground

6 – No

connection

7

No

connection

8

No

connection

9

No

connection

RS-232 Programmer’s Guide

Host-to-VTG communications

SIS commands consist of one or more characters per field. No special characters

are required to begin or end a command sequence. When the VTG determines

that a command is valid, it executes the command and sends a response to the

host device. All responses from the video test generator to the host end with a

carriage return and a line feed (CR/LF = ), which signals the end of the

response character string. A string is one or more characters.
It is also possible to send several SIS commands back-to-back in sequence.

Video test generator-initiated messages

When a local event such as a top panel selection or adjustment takes place, the

VTG responds by sending a message to the host. No response is required from

the host. An example of a video test generator-initiated message is listed here

(underlined).
(C) Copyright 2004, Extron Electronics, VTG 400, Vx.xx

The VTG sends the copyright message when it first powers on. Vx.xx is the

firmware version number.

Error responses

When the video test generator receives a valid SIS command, it executes the

command and sends a response to the host device. If the VTG is unable to

execute the command because the command is invalid or it contains invalid

parameters, it returns an error response to the host.
The error response codes and their descriptions are as follows:
E05 – VTG 400 power is off and an attempt has been made to send it a command.
E07 – An attempt to select a nonexistent test pattern number has been made.
E08 – An attempt to select a nonexistent scan rate number has been made.

E10 – Invalid command
E11 – Invalid preset #

E13 – Invalid value (out of range)
E23 – Checksum error

DB9 Pin Locations

Female

5

1

9

6
