A-3

PIP 422 and PIP 444 Picture-in-Picture Processors • Specifications and Part Numbers

Sync

Genlock connectors (PIP 444) .... 1 BNC female for genlock input

1 BNC female for genlock output (terminate with 75 ohms if unused)

Standards

Input .................................. NTSC 3.58, NTSC 4.43, PAL, SECAM
Output ............................... NTSC 3.58, PAL

Control/remote — processor

Serial control port ........................ RS-232 or RS-422, 9-pin female D connector
Baud rate and protocol ............... 115200, 38400, 19200, or 9600 (default) baud (configurable); 8 data bits; 1

stop bit; no parity

Serial control pin configurations RS-232: 2 = TX, 3 = RX, 5 = GND

RS-422: 2 = TX-, 3 = RX-, 5 = GND, 7 = Rx+, 8 = Tx+

Program control ........................... Extron’s control/configuration program for Windows

®

Extron’s Simple Instruction Set (SIS

)

General

Power ............................................. 100 VAC to 240 VAC, 50/60 Hz, 10 watts, internal, autoswitchable
Temperature/humidity .............. Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing

Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing

Rack mount ................................... Yes, with included brackets
Enclosure type .............................. Metal
Enclosure dimensions ................. 1.75" H x 17.5" W x 8.5" D (1U high, full rack wide)

4.4 cm H x 44.4 cm W x 21.6 cm D
(Depth excludes connectors and knobs. Width excludes rack ears.)

Product weight ............................. 7.0 lbs (3.2 kg)
Shipping weight ........................... 10 lbs (5 kg)
Vibration ....................................... ISTA 1A in carton (International Safe Transit Association)
Listings .......................................... UL, CUL
Compliances ................................. CE, FCC Class A, VCCI, AS/NZS, ICES
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor

All nominal levels are at ±10%.

Specifications are subject to change without notice.
