Page 46

background image

Remote Control, cont’d

PIP 422 and PIP 444 Picture-in-Picture Processors • Remote Control

4-10

Command/response table for special function SIS commands (cont’d)

Command

ASCII Command

Response

Additional description

(host to PIP)

(PIP to host)

Control Software for Windows

®

The Windows-based Extron PIP 422 & 444 Control Program, which communicates
with the processor via the RS-232/RS-422 port, provides an easy way to configure
and operate the PIP. The program is compatible with Windows 2000 and
Windows XP.

Installing the software

The program is contained on the Extron Software Products CD-ROM, disk B.
Install the software as follows:

For full functionality, install both of the following programs:

The PIP 422 & 444 Control Program

The Firmware Loader

1

.

Insert the CD-ROM into the drive. The installation program should start
automatically. If it does not self-start, run Launch.exe from the CD.

The Extron software CD window appears (figure 4-2).

Figure 4-2 — Software CD window

Window anti-aliasing filter

Set anti-aliasing filter

X1

*

X27

*7#

Aaf

X1

*

X27

Set anti-aliasing filter for
window

X1

to mode

X27

.

Example:

3*4*7#

Aaf3*4

Set anti-aliasing filter for
window 3 to auto-adjust.

View anti-aliasing mode

X1

*7#

X27

View anti-aliasing filter for
window

X1

.

Baud rate

Change baud rate

Esc X28

CP

Ccp

X28

Change the baud rate to

X28

.
