4-11

PIP 422 and PIP 444 Picture-in-Picture Processors • Remote Control

2

.

Click the Software tab (figure 4-2).

3

.

Scroll to the desired program and click Install (figure 4-3).

Figure 4-3 — Software installation

4

.

Follow the on-screen instructions. By default, the Windows installation of the
PIP 422 & 444 Control Program creates a C:\Program Files\Extron\
PIP 422 & 444 directory, and it places four icons into a group folder named
“Extron Electronics\PIP 422 & 444.” The four installed icons are:

PIP 422 & 444

PIP 422 & 444 Help

Check for PIP 422 & 444 Update

Uninstall PIP 422 & 444

Starting the control program

To run the software:

1

.

Click Start > Programs > Extron Electronics >
PIP 422 & 444 > PIP 422 & 444. The Communication
Connection Settings window appears (figure 4-4).

Figure 4-4 — Communication Connection Settings window

2

.

Select the comm port that is connected to the PIP’s remote connector and the
baud rate at which the PIP is operating. Click Connect.
