Symbol definitions
X4) = Matrix name (Up to 240 alphanumeric characters)
NOTE: The HTML language reserves certain characters for specific functions (see “ Special Characters “ on page 95).
X4! = Default name MTPX - + last 3 pairs of MAC address
X4@ = Time and date (for set) In the format: MM/DD/YY•HH:MM:SS where:
MM = month: 01 (January) through 12 (December)
DD = 01 through 31
YY = 00 through 99
HH = 00 through 23
MM = 00 through 59
SS = 00 through 59
X4# = Time and date (for read) In the format: Day,•DD•Mmm•YYYY•HH:MM:SS where:
Day of the week: Mon through Sun
DD = 01 through 31
Mmm = month: Jan through Dec
YYYY = 2000 through 2099
HH = 00 through 23
MM = 00 through 59
SS = 00 through 59
X4$
= GMT offset –12.0 through +14.0. Hours and minutes removed from GMT
X4% = Daylight Savings Time 0 = Daylight Savings Time off/ignore
1 = Daylight Savings Time on (northern hemisphere)
2 = Daylight Savings Time on (Europe)
3 = Daylight Savings Time on (Brazil)
X4^ = IP address ###.###.###.###
X4& = Hardware (MAC) address ##-##-##-##-##-##
X4*
= Number of open connections 000 - 200
X4( = Password Up to 12 alphanumeric characters
NOTE: The HTML language reserves certain characters for specific functions (see “ Special Characters “ on page 95).
X5)
= Domain name Standard domain name rules apply (for example: xxx.com)
NOTE: The HTML language reserves certain characters for specific functions (see “ Special Characters “ on page 95). The @ character is
acceptable only as the lead-in to the domain name (such as @extron.com).
X5! = E-mail account 65 - 72. 65 = e-mail recipient 1, 66 = 2, 67 = 3, ... 72 = recipient #8
X5@ = E-mail address Typical e-mail address format (for example: [email protected])
X5#
= Notify when? 0 = no response 3 = both 1 & 2
1 = fail/missing 4 = suspend
2 = fixed/restored
X5$ = Notification selections 00 = both fans, 01 (fan 1), or 02 (fan 2)
X5% = Notify status (for read) 17-digit number. For each digit: 0 = do not notify, 1 = notify
X5^ = DHCP 0 = off, 1 = on
X5& = Port # 00 through 99 (00 = all ports)
X5*
= Baud rate 9600, 19200, 38400, 115200
X5( = Parity odd, even, none, mark, space (only the first letter required)
X6)
= Data bits 7, 8
X6! = Stop bits 1, 2
X6@ = Port type 0 = RS-232
1 = RS-422
2 = RS-485
MTPX Plus Series • Programming Guide 93
