Address and Name fields
The Matrix IP Address field contains the IP address of the connected matrix switcher.
This value is encoded in the flash memory in the switcher.
The
Gateway IP Address field identifies the address of the gateway to the controlling PC
to be used if the matrix switcher and the mail server are not on the same subnet.
The
Subnet Mask field is used to determine whether the matrix switcher is on the
same subnet as the controlling PC when you are subnetting. For more information, see
“
Subnetting — A Primer ” in the “Ethernet Link” section on page 151.
The Mail Server IP Address field displays the IP address of the mail server that handles
the e-mail for the facility in which the MTPX Plus switcher is installed.
Valid addresses consist of four 1-, 2-, or 3-digit numeric subfields, properly called octets,
separated by dots (periods). Each octet can be numbered from 000 through 255. Leading
zeroes, up to 3 digits total per field, are optional. Values of 256 and above are invalid.
The default addresses are as follows, but if these conflict with other equipment at your
installation, you can change the addresses to any valid value:
• IP address 192.168.254.254 • Gateway address 0.0.0.0
• Subnet mask 255.255.0.0
NOTES: • The address fields are unavailable when DHCP is selected.
• Editing the addresses while connected via the Ethernet port can immediately
disconnect the user from the MTPX. Extron recommends editing this
field using one of the RS-232 ports and protecting the Ethernet access
by assigning an administrator password to qualified and knowledgeable
personnel only.
The Extron Name/Descriptor field contains the name of the matrix switcher. This
descriptor can be changed to any valid name, up to 12 alphanumeric characters.
The
Mail Server Domain Name field displays the domain name that the MTPX Plus
switcher uses to log on to the e-mail server. Standard domain conventions (such as xxx.com)
apply.
NOTE: The HTML language reserves certain characters for specific functions (see
“ Special Characters “ in the “Programming Guide” section). In the Mail
Serve Domain Name field, the @ character is only acceptable as the lead-in to
the domain name (such as @folklore.net).
Edit any of these fields as follows:
1. Click in the desired field. The graphic cursor becomes a text cursor.
2. Edit the address or name as desired.
3. Press the key on the keyboard or click in another field to exit the field.
4. Click the Take button to make the address change take affect.
