Extron Electronics MTPX Plus Series User Guide - Manual (Page 97)

Command/Response Table for SIS Commands (continued)
Command Function SIS Command
(Host to Unit)
Response
(Unit to Host)
Additional description
View ties, gain, volume, mutes, presets, and DIP switch status (continued)
NOTE :
The response to the View File Directory command differs, depending on whether the command is sent via an RS-232/RS-422 or
Telnet connection or sent via a Web browser connection.
View file directory
RS-232/RS-422 port and Telnet E DF } filename1,date/time,length]
filename2,date/time,length]
filename3,date/time,length]
• •
• •
filenamen,date/time,length]
# of Bytes•Left]
]
List user-supplied files.
View file directory
Web browser E DF } Var file = new array (); List user-supplied files.
File [1] = ‘filename1,date1,filesize1‘;
File [2] = ‘filename2,date2,filesize2‘;
File [3] = ‘filename3,date3,filesize3‘;
• •
• •
File [n] = ‘filenamen,daten,filesizen‘;
File [n+1] = # of Bytes•Left
Erase user-supplied Web pages/files E filenameEF } Delfilename ]
Information requests
Information request I V X2( X X3) •A X2( X X3)] V (video) matrix size•
A (audio) matrix size
Request part number N X3!] See “ Part Numbers and
Accessories ” in the “Reference
Information” section.
NOTE : There are up to three separate sets of Extron firmware on which the switcher can report: the controller firmware, which is the
overall control firmware; the Ethernet protocol firmware, which handles the Ethernet interface; and the latest optional Extron
firmware update, which is available at
www.extron.com .
Query controller firmware version Q X3@]
Example: Q 1.23 ] The factory-installed controller firmware
version is 1.23 (sample value only).
Query controller firmware version
(verbose) 0Q X3@ - X3# - X3#] Provide a detailed status of the MTPX
Plus controller firmware and any
firmware upgrade. The firmware that
is running is marked by an asterisk (*).
A caret (^) indicates that the firmware
has a bad checksum or an invalid load.
?.?? indicates that firmware is not
loaded.
Response description: Ethernet protocol firmware version-controller firmware version-updated firmware version]
Example:
0q
Ethernet protocol
firmware
Description
MTPX firmware version Updated firmware version
* indicates the version running Upload date and time
1.23-1.00(1.06-16x16 Series -Tue, 04 Dec 2007 00:00:00 GMT)-1.00*(1.06-16x16 Series -Thu, 27 Dec 2006 16:39:21 GMT)
NOTE: X2( = Number of inputs 8, 12, 16, or 32
X3) = Number of outputs 8, 16, or 32
X3! = Part number 60-nnn-nn
X3@ = Firmware version number to second decimal place (x.xx)
X3# = Verbose firmware version-description-upload date/time
MTPX Plus Series • Programming Guide 91
