Preset button — The Preset button has two primary functions (❏) and three
secondary functions (•):
❏
Activates
Save Preset mode to save a configuration as a preset and Recall Preset
mode to activate a previously-defined preset.
❏
Blinks when Save Preset mode is active and lights steadily when Recall Preset mode
is active.
•
In the I/O Group mode, selects group 2 and indicates the selection.
•
With the Enter, View, and Esc buttons, selects Serial Port and Audio/RS-232 Input
Configuration mode.
•
Selects 19200 baud for the rear panel Remote port in Serial Port and Audio/RS-232
Input Configuration mode and indicates the selection.
e
View (<) button — The View (<) button has one primary function (❏) and five
secondary functions (•):
❏
Select and indicate View-only mode, which displays the current configuration.
NOTE: View-only mode also provides a way to mute and unmute the audio or
RS-232 outputs.
•
In the I/O Group mode, selects group 3 and indicates the selection.
•
Decreases the audio level of the selected input.
•
Decreases the volume of the selected output.
•
With the Enter, Preset, and Esc buttons, selects Serial Port and Audio/RS-232 Input
Configuration mode.
•
Selects 38400 baud for the rear panel Remote port in Serial Port and Audio/RS-232
Input Configuration mode, and indicates the selection.
f
Esc (>) button — The Esc (>) button has two primary functions (❏) and five secondary
functions (•):
❏
Cancels operations or selections in progress and resets the front panel button
indicators.
NOTE: The Esc (>) button does not reset the current configuration, the Video
button and Audio selection button, any presets, or any audio gain or
attenuation or volume settings.
❏
Flashes once to indicate that the escape function has been activated.
•
In the I/O Group mode, selects group 4 and indicates the selection.
•
Increases the audio level of the selected input.
•
Increases the volume of the selected output.
•
With the Enter, Preset, and View buttons, selects Serial Port and Audio/RS-232 Input
Configuration mode.
•
Selects 115200 baud for the rear panel Remote port in Serial Port and Audio/RS-232
Input Configuration mode and indicates the selection.
