X6#
= Verbose mode
0 = clear/none (default for Telnet connection)
1 = verbose mode (default for RS-232/RS-422 connection)
2 = tagged responses for queries
3 = verbose mode and tagged for queries
NOTE: If tagged responses is enabled (modes 2 and 3), all read commands return the constant string and the value as the set command
does (for example, the read matrix name command
E
CN
}
, returns Ipn•
X4)]
).
X6$
= Flow control
hardware, software, none (only the first letter required)
X6%
= Data pacing (in ms between bytes)
0000 (default) - 1000
X6^
= Time (in 10 ms increments) to wait for characters
10 (= 100 ms, default) - 32767
X6&
= Time (in 10 ms increments) to wait between characters
2 (= 20 ms, default) - 32767
X6*
= Port timeout interval (in 10-sec. increments)
1 (= 10 seconds) - 65000 (default is 30 = 300 seconds = 5 minutes)
Command/Response Table for IP-specific SIS Commands
Command Function
SIS Command
(Host to Unit)
Response
(Unit to Host)
Additional description
IP setup commands
Set matrix name
EX4)
CN
}
Ipn•
X4)]
Read matrix name (location)
E
CN
}
X4)]
Reset matrix name to factory default
E
•CN
}
Ipn•
X4)]
Set time and date
E
X4@
CT
}
Ipt
X4@]
Read time and date
E
CT
}
X4#]
Set GMT offset
EX4$
CZ
}
Ipz
X4$]
In the command, the divider between
hours and minutes can be either a
colon or a period. In the response, the
divider is a colon.
Example:
E
8.3CZ
}
Ipz+08:30
]
8.3 = 8:30
Read GMT offset
E
CZ
}
X4$]
Set Daylight Savings Time
EX4%
CX
}
X4%]
Read Daylight Savings Time
E
CX
}
X4%]
Set IP address
EX4^
CI
}
Ipi
X4^]
Read IP address
E
CI
}
X4^]
Read hardware address
E
CH
}
X4&]
Reads MAC address.
Read # of open connections
E
CC
}
X4*]
Set subnet mask
EX4^
CS
}
Ips
X4^]
Read subnet mask
E
CS
}
X4^]
Set gateway IP address
EX4^
CG
}
Ipg
X4^]
Read gateway IP address
E
CG
}
X4^]
Set administrator password
EX4(
CA
}
Ipa•
X4(]
Read administrator password
E
CA
}
X4(]
Reset (clear) administrator password
E
•CA
}
Ipa•
]
Set user password
EX4(
CU
}
Ipu•
X4(]
Read user password
E
CU
}
X4(]
Reset (clear) user password
E
•CU
}
Ipu•
]
Set mail server, domainname
EX4^
,
X5)
,
X4(
CM
}
Ipm
X4^
,
X5)
,
X4(]
Read mail server, domainname
E
CM
}
X4^
,
X5)
,
X4(]
Set e-mail recipient
EX5!
,
X5@
CR
}
Ipr
X5!
,
X5@
,
]
This command sets the recipient. To
receive e-mail notifications, you must then
set the events that the switcher reports,
using one or more separate Set e-mail
events (EM) commands (see next page).
Example:
E
}
Ipr72,[email protected]
,
]
Read e-mail recipient
EX5!
CR
}
X5@
,
]
