Configuration Tab
System Settings Page
The MTPX Plus switcher downloads the System Settings page (see
the
Configuration
tab. The screen consists of fields in which you can view and edit IP
administration and system settings. You can access the Email Settings and Passwords pages
by clicking the appropriate link. See “
” on page 146 for basic information
about IP addresses and subnetting.
Select Passwords
Refresh
Select Firmware Upgrade
Select Email Settings
Figure 78.
System Settings Page
On password-protected connections, there are two levels of protection: administrator and
user. Administrators have full access to all switching capabilities and editing functions. Users
can create ties, create and recall presets, set audio or RS-232 mutes, and view all settings
with the exception of passwords.
IP Settings fields
The IP Settings fields provide a location for viewing and editing settings unique to the
Ethernet interface. After editing any of the settings on this page, click the
Submit
button at
the bottom of the page.
Unit Name field
The Unit Name field contains the name used as the “from” information when the switcher
e-mails notification of its failed or repaired status. This name field can be changed to any
valid name, up to 24 alphanumeric characters.
NOTE: The
HTML language reserves certain characters for specific functions (see
“
“ in the “Programming Guide” section).
MTPX Plus Series • HTML Operation 129
