Reference
Information
This section discusses the specifications, part numbers, and accessories for the
MTPX Matrix Switchers. Topics that are covered include:
• Specifications
• Part Numbers and Accessories
• Mounting the Switcher
• Button Labels
Specifications
Video
Routing
MTPX Plus 816 ................. 8 x 16 matrix, 3 x 1 local
MTPX Plus 128 ................. 12 x 8 matrix, 4 x 2 local
MTPX Plus 168 ................. 16 x 8 matrix, 3 x 1 local
MTPX Plus 1616 ............... 16 x 16 matrix, 3 x 1 local
MTPX Plus 1632 ............... 16 x 32 matrix, 6 x 2 local
MTPX Plus 3216 ............... 32 x 16 matrix, 6 x 2 local
MTPX Plus 3232 ............... 32 x 32 matrix, 6 x 2 local
Gain ............................................ Unity ±1 dB
Crosstalk
128 models ...................... -76 dB @ 1 MHz, -55 dB @ 10 MHz, -45 dB @ 30 MHz, -30 dB @ 100 MHz
816, 168, 1616 models .... -80 dB @ 1 MHz, -71 dB @ 5 MHz, -55 dB @ 10 MHz, -45 dB @ 30 MHz, -37
dB @ 100 MHz
1632, 3216, 3232 models -90 dB @ 1 MHz, -76 @ 5 MHz, -72 dB @ 10 MHz, -60 dB @ 30 MHz, -50 dB @
100 MHz
Switching speed .......................... 200 ms (max.)
Video input — local
Number/signal type ..................... 3, 4, or 6 analog RGBHV, RGBS, RGsB, RsGsBs, component video (bi-level and
tri-level), S-video, composite video
Connectors ................................. 3, 4, or 6 female 15-pin HD
Nominal level .............................. 1 Vp-p for Y of component video and S-video, and for composite video
0.7 Vp-p for RGB and for R-Y and B-Y of component video
0.3 Vp-p for C of S-video
Impedance .................................. 75 ohms ±5%
Horizontal frequency ................... 15 kHz to 130 kHz
Vertical frequency ........................ 30 Hz to 150 Hz
Return loss .................................. <-30 dB @ 5 MHz
DC offset (max. allowable) .......... 250 mV
MTPX Plus Series • Reference Information 153
