Control/remote — external device (pass-through, unidirectional, or bidirectional)

Serial control ports ...................... RS-232, 3.5 mm captive screw connectors, 3 pole

3232 and 1632 models .... 16 connectors
3216, 1616, 128, and 816 models ..... 8 connectors
168 models ...................... 4 connectors

Baud rate and protocol ................ Up to 38400 baud, 9600 baud (default); 5-8 data bits; 1 or 2 stop bits; odd,

even, or no parity; XON, XOFF, or no flow control

NOTE:

Protocol is mirrored between the switcher and the receiver.

Serial control pin configurations .. 1 = Tx, 2 = Rx, 3 = GND

General

Recommended cable type ........... Shielded or unshielded CAT 5/5e/6/7 or

Extron Enhanced Skew-Free

A/V UTP

Power ......................................... 100 VAC to 240 VAC, 50-60 Hz, internal

1632, 3216, 3232 models 220 watts
816, 168, 1616 models .... 120 watts
128 model ........................ 73 watts

Temperature/humidity ................. Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing

Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing

Cooling ....................................... Fan, left to right (as viewed from the front panel)
Thermal dissipation

128 model

115 VAC, 60 Hz ........ 231.1 BTU/hr
240 VAC, 50 Hz ........ 223.8 BTU/hr

1616 model

115 VAC, 60 Hz ........ 348.3 BTU/hr
240 VAC, 50 Hz ........ 353.0 BTU/hr

3232 model

115 VAC, 60 Hz ........ 607.1 BTU/hr
240 VAC, 50 Hz ........ 595.3 BTU/hr

Rack mount ................................. Yes
Enclosure type ............................. Metal
Enclosure dimensions .................. Depth excludes connectors, width excludes rack ears.

1632, 3216, 3232 models 5.25" H x 17.0" W x 9.4" D (3U high, full rack wide)

(13.3 cm H x 43.1 cm W x 23.9 cm D)

816, 168, 1616 models .... 3.5" H x 17.0" W x 9.4" D (2U high, full rack wide)

(8.9 cm H x 43.1 cm W x 23.9 cm D)

128 model ........................ 1.7" H x 17.4" W x 12.0" D (1U high, full rack wide)

(4.3 cm H x 44.2 cm W x 30.5 cm D)

Product weight

1632, 3216, 3232 models 16.0 lbs (7.3 kg)
816, 168, 1616 models .... 8.5 lbs (3.9 kg)
128 model ........................ 3.7 lbs (1.6 kg)

Shipping weight

1632, 3216, 3232 models 26 lbs (ll.8 kg)
816, 168, 1616 models .... 18 lbs (9 kg)
128 model ........................ 7 lbs (4 kg)

DIM weight (International)

1632, 3216, 3232 models 26 lbs (11.8 kg)
816, 168, 1616 models .... 18 lbs (9 kg)
128 model ........................ 7 lbs (4 kg)

Vibration ..................................... ISTA 1A in carton (International Safe Transit Association)

MTPX Plus Series • Reference Information 156
