Rack mounting — The 1U high (MTPX Plus 128), 2U high (other matrix sizes 1616
and smaller), or 3U high (matrix sizes 1632 and larger) enclosure is rack mountable in any
conventional 19-inch wide wide rack. The 2U and 3U enclosures are mountable without
extra hardware. The 1U enclosure is rack mountable using the provided mounting kit.
Three front panel security lockout modes (Executive modes) — If a matrix
switcher is installed in an open area, where operation by unauthorized personnel may be
a problem, either of two security lockout modes can be implemented (the third mode is
unlocked). When a front panel lockout mode is enabled, a special button combination or
SIS command is required to unlock the front panel controls and make the front panel fully
operational.
Power — The 100 VAC to 240 VAC internal power supply provides worldwide power
compatibility.
MTPX Plus Series • Introduction
