X1%
= TP output number
01 – (maximum number of TP outputs for your model)
X1^
= Local video output number
1 or 2
NOTE:
X1^
is applicable to MTPX Plus 128 and matrix sizes 1632 and larger only.
X1&
= Local output sync polarity
0 = H- / V- (default)
3 = H+ / V+
1 = H+ / V-
4 = No sync processing (composite, S-video, YUV)
2 = H- / V+
X1*
= Local audio output number
1 – 2 (MTPX Plus 128)
1 – 4 (other matrix sizes 1616 and smaller)
1 – 8 (matrix sizes 1632 and larger)
X1(
= Volume adjustment range
0 – 64 (1 dB/step except for 0-to-1, which is 13 dB) (default = 64 [0 dB])
(
on page 84.)
X2)
= Audio gain
0 – 24 (1 dB/step)
X2!
= Numeric dB value
–18 to +24 (45 steps of gain or attenuation) (Default = 0 dB)
X2@
= Audio attenuation
1 – 18 (1 dB/step)
X2#
= Global or room preset #
00 - 32 (global) or 00-10 (room) (0 = current configuration)
NOTE:
A Room preset is a stored configuration with all of the outputs assigned to a single room. When a room preset is recalled from
memory, it becomes the current configuration.
X2$
= Name
12 characters maximum for input, output, and global preset names
11 characters maximum for room preset names
Upper- and lower-case alphanumeric characters and
_ / and spaces are valid.
NOTE:
The HTML language reserves certain characters for specific functions (see “
“ on page 95).
X2%
= Room # (for room presets)
10 max. (each can have up to 10 presets (
X2#
s) assigned)
NOTE:
A Room is a subset of operator-selected outputs that relate to each other. The MTPX Plus switchers support up to 10 rooms, each of
which can consist of from 1 to 16 outputs.
X2^
= Group # (for I/O grouping)
1 through 4 groups (0 = no group)
X2&
= Audio or RS-232 mute:
0 = no mutes
2 = audio or RS-232 mute
X2*
= Local input select DIP switch status
0 = RJ-45 position
1 = local input position
X2(
= Number of inputs
8, 12, 16, or 32
X3)
= Number of outputs
8, 16, or 32
X3!
= Part number
60-nnn-nn or 60-nnnn-nn
X3@
= Firmware version number to second decimal place (x.xx)
X3#
= Verbose firmware version-description-upload date/time (see the
Query firmware version (verbose)
command on page 91).
X3$
= Voltage
Positive or negative voltage and magnitude
X3%
= Internal temperature
Degrees Fahrenheit
X3^
= Fan speed
RPM
