Programmer’s Guide, cont’d
Fiber Matrix 6400 Switcher • Programmer’s Guide 4-16
Command/response table for SIS commands (continued)
Command ASCII command
(host to switcher)
Response
(switcher to host)
Additional
description
Information requests (continued)
Query controller firmware
version (verbose) 0Q X1(
-
X2)
-
X2)] Provide a detailed status
of the Ethernet protocol
firmware, the controller
firmware, and any firmware
upgrade. The firmware that
is running is marked by
an asterisk (*). A caret (^)
indicates that the firmware
has a bad checksum or an
invalid load. ?.?? indicates
that firmware is not loaded.
Response description: Ethernet protocol firmware version-controller firmware version-updated firmware version ]
Example: 0q
Ethernet protocol
firmware
1.23-1.00(1.68-FOMX Series -Wed, 20 Feb 2008 00:00:00 GMT)-1.00*(1.06-FOMX Series -Mon, 17 Mar 2007 16:39:21 GMT)
Description
Fiber Matrix firmware version Updated firmware version
* indicates the version running Upload date and time
Request system status S X2!
•
X2!
•
X2!
•
X2!
•
X2!
•
X2!
•
X2!
•
X2@
•
X2#
•
X2#]
Response description:
+3.
3V•+5V•+2.5V•+1.2V•+12V (backplane)•+12V (redundant supply)•+12V (primary supply)•Temp•Fan1 RPM•Fan2 RPM
]
Example: S
3.27•4.95•2.48•1.22•12.00•12.06•12.12•+080.60•03013•02860
Backplane receiving 12.00 V Internal temperature 80.6° F
Fan 1 rotating at 3,013 RPM 3.3 V power system at 3.27 V
N The response to the View File Directory command differs, depending on whether the command is sent via an
RS-232/RS-422 or Telnet connection or sent via a Web browser connection.
View file directory
RS-232/RS-422 port and
Telnet E
DF
}
filename 1,date/time,length
]
filename 2,date/time,length ]
filename 3,date/time,length
]
• •
• •
filename n,date/time,length
]
# of Bytes
•
Left
]]
List user-supplied files.
View file directory
Web browser E
DF
} Var file = new array (); List user-supplied files.
File [1] = ‘filename1,date1,filesize1‘;
File [2] = ‘filename2,date2,filesize2‘;
File [3] = ‘filename3,date3,filesize3‘;
• •
• •
File [n] = ‘filenamen,daten,filesizen‘;
File [n+1] = # of Bytes•Left
Erase user-supplied Web
pages/files E filename EF } Delfilename ]
N
X1(
= Firmware version number to second decimal place (x.xx)
X2)
= Verbose firmware version-description-upload date/time.
X2!
= Voltage Positive or negative voltage and magnitude
X2@
= Temperature Degrees Fahrenheit
X2#
= Fan speed (in RPM)
