3-23 Fiber Matrix 6400 Switcher • Operation
4 . Confirm the change : Press and release the Enter button. The configuration
stored in the selected memory location is now the current configuration and
can be viewed in the View-only mode (see example 4).
C O N T R O L
PRESET ENTER ESC VIEW
The Enter and Preset
buttons return to unlit or
background illumination.
Press the Enter button to
recall the preset.
All input buttons and output
buttons return to unlit or
background illumination.
Muting and unmuting outputs
Individual outputs can be muted or unmuted as follows:
1 . Press the Esc button to clear any front panel button indications that may be
on.
2 . Press and release the View button.
3 . One at a time, press and hold the button(s) for the desired output(s) for
approximately 2 seconds. The output button(s) for the selected output(s)
blink to indicate the mute or return to their previous state to indicate the
unmute.
4 . Press and release the View button to return to normal switcher operation.
N • When you enter View-only mode, the output buttons light for all outputs
without ties.
• Mutes are saved to non-volatile memory. When power is removed and
restored, the mute settings are retained.
