DSP Configurator Windows Menus
The DSP Configurator program is fully navigable using the computer keyboard. Some
keyboard navigation behavior matches Windows standards, while other behaviors are
specific to DSP Configurator.
Keyboard Navigation
When the program starts, the cursor focus defaults to the mic/line input gain block
(figure 56, a). The input 1 gain block is highlighted green [
]. The key toggles to
the various sections outlined in red in figure 56.
Within the sections, the can be used to move one block right, left,
up, or down within these sections.
NOTE: The callout numbers for figure 56 are not the same as figure 17.
a
b
c d
e f g
Figure 56. DSP Configurator Program Window
Standard Windows Navigation
The keyboard keys navigate and function as follows:
• Tab key —
Sequentially jump among major segments of the DSP Configurator program. From the
audio input chains (a), sequential jumps are in the following order:
b Main mix-points
c Virtual return signal path
d Virtual return mix-points
e Output signal chain
f Mode (toggles to Live , then Emulate )
g Presets ( arrow can select presets)
DMP 64 • Software Control 85
