Embedded Web Pages
The embedded web pages, accessible by LAN using a web browser, include the following
information, available in a tabbed interface.
•
System Status — The opening web page, displaying a report of system status
parameters.
•
Configuration — This tab contains the following menu items.
•
System Settings. Contains IP address and date/time settings.
•
Passwords. Enter/re-enter admin and user password fields to set up password
protected access.
•
Firmware Upgrades. Browse/upload firmware to the device.
•
File Management — Delete or upload files
•
Control — Contains the following menu items:
•
Audio Settings. Includes mix matrix, input and output gain control.
•
Group Controls. Provides access-only to the group controls.
•
Presets. Used to save new presets created on Audio Settings page.
See
on page 120 for further details.
Windows-based Program Control
The DSP Configurator Control Program is compatible with Windows 2000, Windows XP,
and Vista, and provides remote control of the input gain/attenuation, output volume
output adjustment, and other features.
DSP Configurator can control the DMP 64 using any of the three control ports, RS-232,
USB, or LAN.
Updates to this program can be downloaded from the Extron website at
www.extron.com.
Installing the DSP Configurator Program
The program is contained on the Extron Software Products disk.
Install the software as follows:
1.
Insert the disk into the drive
