Command and Response Tables for DSP SIS Commands
Many digital signal processor (DSP) functions; gain, mute, group masters, and a protected
configuration can be controlled using SIS commands. These commands follow the same
general rules as basic SIS commands, but the variables (X/) tend to be more complex.
Also, a comprehensive understanding of the audio signal flow is helpful to understanding
the commands. Figure 61 shows specific DSP functions available using SIS commands.
NOTE: The entire signal flow is described in more detail in the DSP Configurator
a
b c
e
f
d
Ñ
Figure 61.
DSP Processors Addressable by SIS Commands
a
Mic/line input gain block (including gain and mute)
b
Pre-mixer gain block (including gain and mute)
c
Mix-points (including gain and mute)
Ñ
Virtual return mix-points
d
Post-mixer trim block (gain only)
e
Output volume (including gain and mute)
f
Virtual return gain
