Pre-mixer Gain (GAIN)
The post-input processing gain control (also called the pre-mixer
gain) provides gain or attenuation post-processing gain block. It
includes a mono long-throw fader with a – 100.0 to +12.0 dB gain
range, and a current level setting readout below the fader. Fader
adjustments are in 1 dB increments, while adjustments can be
entered manually to 0.1 dB resolution.
Default is unmuted at unity (0.0 dB) gain.
Selecting the fader handle with the mouse or clicking within the fader
area brings focus to the fader. The input signal level can be adjusted
using any of the following methods:
• Select and hold the fader handle, then drag it to desired level in
1.0 dB steps.
• Select or tab to the fader handle, then use the up/down arrow to
set the desired level in 1 dB steps.
and increases and decreases level in 5 dB steps.
Click in or tab to the level readout field. Type a new value, then press or to
another area. .
DMP 64 • Software Control 55
