DSP Configurator Toolbar Menus

The DSP Configurator contains the following structural menus, arranged horizontally
below the title bar:

File

NOTE:

New

,

Open

, and

Recent Files

are unavailable in Live

mode.

New — Discards the current DSP configuration (after prompting to

save any changes) and opens a blank configuration file.

Open — Loads and activates a previously saved DSP

configuration file.

Save — Saves all changes to the current DSP configuration file

under the current file name. If the file has not previously been
saved, prompts for a file name.

Save As — Saves all changes to the current DSP configuration

file under a new file name.

Backup — Transfers all partial presets plus the current configuration to a DSP

configuration file within the DSP Configurator program.

Recent Files — Opens a list of recently opened or saved DSP configuration files.

Exit — Closes the DSP Configurator Program.

Edit

Cut — Removes all parameters of a selected

processor block or set of selected blocks to the
clipboard. If not followed by a

Paste

command to a

different block, the parameters are restored.

NOTE: Processor blocks are not removed from the processor stream after a

Cut

and a subsequent

Paste

operation. Only the parameters are moved.

Processor blocks and their parameters can be pasted only into another block of

the same type. For example, the input 1 filter block and all of its parameters can
be copied to the input 2 filter block but not to the input 1 delay block.

Copy — Copies all of the parameters of a selected processor block, gain block, or

set of selected blocks to the clipboard.

Paste — Inserts processor blocks and their parameters from the clipboard into the

selected location.

DMP 64 • Software Control

22
