Installation
This section describes the installation of the DMP 64, including:
• Mounting the DMP 64
• Rear Panel Features and Cabling
Mounting the DMP 64
The 1U high, half rack width, 9.5 inch deep DMP 64 Digital Matrix Processor can be:
• Set on a table,
• Mounted on a rack shelf,
• Mounted under a desk or tabletop, or
• Mounted on a projector bracket.
For detailed mounting options and UL rack mounting guidelines (see Mounting the
DMP 64 on page 139).
Rear Panel Features and Cabling
DMP 64
POWER
12V
1.0A MAX
RESET
LAN
1 2 3
4 5 6
4 5 6
1 2
3 4
Tx Rx G
RS-232 (2)
Tx Rx G
RS-232 (1)
4 5 6 G
1 2 3 G MIC
+48V
1 3 2
MIC/LINE INPUTS
OUTPUT
S
I/O
REMO
TE
a b c d e f g hi
Figure 1. DMP 64 Rear Panel
NOTE: Control signal ground pins may be labeled as or “G”. Audio ground pins may
be labeled as or .
The wiring and function are the same, whichever way your product is labeled.
DMP 64 • Installation 5
