98 EN 3.05 MagFlux Manual 1212
Electromagnetic Flow Meter
Modbus
The MagFlux ® is delivered with a standard Modbus RTU protocol, and up
to four MagFlux ® converters can be connected for concurrent operation.
Time Format
24 Hour
AM/PM
Back Select OK
Change Device Address
Device 1
Back Select OK
Add Device
Change Device Address
Remove Device
Change Display ID No.
Set No. of Retries
Back Select OK
Scanning
Back
Display 841xxx-xxx
Build Sep 15 2006 11:18:24
Language 2006 09 21
Back
Set Clock Language Modbus Display SW Version
Add Device
Devices Found
Device 1
Back OK
Change Device Addresse
Change Device 1
1
Back Select OK
Remove Device
Device 1
Back Select OK
Remove Device
Language
Set Clock
Modbus
Factory Settings
Display SW Version
Back Select OK
Set Clock
2006-09-19 12:43:11
Back Select >
Recover Factory Settings
Cancel
Delete Log
Restore Default Language
Restore Factory Settings
Back Select OK
Factory Settings
Display Setup
Password Specify Main Screen Factory Settings Data Logger Set Sensor Name Display Setup Converter Setup
Main Menu
.
.
Service Menu
.
Language
(GB) English
(US) English
Dansk
Deutsch
Español
Français
Italiano
Nederlands
Norsk
Soumalainen
Svenska
Back Select OK
Change Display ID No.
1
Back Select OK
Change Display ID No.
Number of Displays
1
Back Select OK
Set No. of Retries
005
This will reset the display.
Back Select >
Set No. of Retries
When several converters are to be added, it is necessary to change each
converter device address to a unique ID address before connecting the
converter to the Display Unit.
Add Device
Four MagFlux
® Converters can be connected to one Display Unit using
the RS485 interface connection. Note that only one Display Unit can be
used with several converters.
The Display Unit can easily be moved to another converters for readout
and configuration.
1. Select "Add Device", click OK and wait for the scan process to finish.
2. The found converters are finally displayed.
Change Device Address
To change each converter's device adress it is required that you connect
