1. Apply power to the sensor.
2. When the "Sensor Calibration Code" menu appears (see below), enter
the calibration code read from the converter label and press OK.
Sensor Calibration Code
|
Back Select >
S/N not entered
Set Flow Direction
Follow Arrow A
Follow Arrow B
Back Select OK
MagFlux1
Flow 0.00 m 3 /h
FTot 00.000 m 3
Select Setup
Service Menu
Sensor Calibration Code
Converter SW Ver.
Product Data
Reset Counter Time
Internal Meas. & Cal.
Minimum Velocity
Calibrate Flow now
Calibrate Volume
Calibrate mA
Test Velocity
Freeze Coil
Read Event Log
Back on Stock
Back
Select OK
Set Flow Direction
Follow Arrow A
Follow Arrow B
Back Select OK
Sensor Calibration Code
Sensor Calibration Code
dw5uq4
Back Select OK
Sensor Calibration Code
A B
A B
3. Select the correct flow direction from the "Set Flow Direction" menu
and press OK.
4. Sensor calibration code configuration is now finished, and you are
returned to the Main Menu.
