Appendix h. remote slave display unit, Electromagnetic flow meter – Xylem Magflux Electromagnetic Flow Meter User Manual
Page 124
124
EN 3.05 MagFlux Manual 1212
Electromagnetic Flow Meter
Appendix H. Remote Slave Display Unit
This example describes the cable connections and display configura-
tions for one MagFlux converter with a local "master" display unit and one
remote "slave" display unit.
Connection Board - with a remote "slave" display unit
Connection for
remote display unit
Plug for local
display unit
+ A B -
10 - 30 V DC
