Electromagnetic Flow Meter
FW: 842018/842009
Data Logger
Magflux ® provides a data logger with a capacity of approx. 20,000 entry
points. See Appendix E on page 120 for examples and descriptions of log
files.
The data logger operates after the FIFO principle (First In, First Out). If the
data logger is full and new data are coming in, the oldest data are dis-
carded.
1. Press the up/down keys to highlight the required menu line (here: Data
Logger) and then press OK to select it.
Specify Main Screen
Factory Settings
Data Logger
Password
Set Sensor Name
Converter Setup
Display Setup
Back Select OK
Main Menu
Data Logger
2. Press the up/down keys to change the highlighted digit, and then press
the right-key (>) to proceed to the next digit.
Set Log Interval
0010 sec
Back Select >
Data Logger
3. Continue until all digits have been set and press OK.
The log interval can be set in intervals from 10 sec. up to 9999 sec.
